20 Tooth 1-1/2″ Bore 50 Pitch Roller Chain Sprocket 50BS20H-1-1/2

Description

Product

50 PITCH ANSI ROLLER CHAIN SPROCKET
Brand new.ANSI standard 50 pitch roller chain sprocket.Bored to size.One-piece carbon steel forged construction with hardened teeth and black oxide finish.Two set screws.Set screws are located directly over the keyway and 90° from keyway.Keyway is on center line of tooth.

SPECIFICATIONS

• Pitch50
• Number of Teeth20
• Bore Size1-1/2&quot
• Model Number50BS20H-1-1/2
• Outside Diameter4.32&quot
• Hub Diameter3&quot
• Hub TypeB (Hub on one side)
• Length Through Bore1&quot
• Keyway Size3/8&quot wide x 3/16&quot depth
• Shpg.3 lbs.
