23 Tooth 1-3/16″ Bore 50 Pitch Roller Chain Sprocket 50BS23H-1-3/16

Description

Product

50 PITCH ANSI ROLLER CHAIN SPROCKET
New.ANSI standard 50 pitch roller chain sprocket.Bored to size.One-piece carbon steel forged construction with hardened teeth and black oxide finish.Two set screws.Set screws are located directly over the keyway and 90° from keyway.Keyway is on center line of tooth.

SPECIFICATIONS

• Pitch50
• Number of Teeth23
• Bore Size1-3/16&quot
• Model Number50BS23H-1-3/16
• Outside Diameter4.92&quot
• Hub Diameter3&quot
• Hub TypeB (Hub on one side)
• Length Through Bore1&quot
• Keyway Size1/4&quot wide x 1/8&quot depth
• Shpg.3 lbs.
