28 Tooth 1-3/4″ Bore 60 Pitch Roller Chain Sprocket 60BS28H-1-3/4

Description

Product

60 PITCH ANSI ROLLER CHAIN SPROCKET
New.ANSI standard 60 pitch roller chain sprocket.Bored to size.One-piece carbon steel forged construction with hardened teeth and black oxide finish.Two set screws.Set screws are located directly over the keyway and 90° from keyway.Keyway is on center line of tooth.

SPECIFICATIONS

• Pitch60
• Number of Teeth28
• Bore Size1-3/4&quot
• Model Number60BS28H-1-3/4
• Outside Diameter7.11&quot
• Hub Diameter4&quot
• Hub TypeB (Hub on one side)
• Length Through Bore1-1/4&quot
• Keyway Size3/8&quot wide x 3/16&quot depth
• Shpg.7 lbs.
