72 Tooth 1-1/4″ Bore 35 Pitch Roller Chain Sprocket 35BS72-1-1/4

Description

Product

35 PITCH ANSI ROLLER CHAIN SPROCKET
Brand new.ANSI standard 35 pitch roller chain sprocket.Bored to size.One-piece carbon steel forged construction with hardened teeth and black oxide finish.Two set screws.Set screws are located directly over the keyway and 90° from keyway.Keyway is on center line of tooth.

SPECIFICATIONS

• Pitch35
• Number of Teeth72
• Bore Size1-1/4&quot
• Model Number35BS72-1
• Outside Diameter8.81&quot
• Hub Diameter2-1/4&quot
• Hub TypeB (Hub on one side)
• Length Through Bore1&quot
• Keyway Size1/4&quot wide x 1/8&quot depth
• Shpg.4 lbs.
